先進積體電路基板：市場佔有率分析、產業趨勢與統計、成長預測（2026-2031）

預計先進積體電路基板市場將從 2025 年的 106.6 億美元成長到 2026 年的 113.7 億美元，到 2031 年將達到 156.6 億美元，2026 年至 2031 年的複合年成長率為 6.63%。

市場需求已從傳統運算轉向以人工智慧為中心的工作負載，這需要更高的層數、更細的線寬和更嚴格的翹曲控制。亞太地區的基板供應商受益於此轉變，因為他們已經擁有強大的ABF產能，並與代工廠的封裝生產線建立了緊密的合作關係。主要雲端服務供應商將長期採購協議的期限提前至2025年，以確保CoWoS和FC-BGA的穩定供應，這進一步增強了基板製造商的定價權。同時，玻璃芯技術的發展日益成熟，為超高密度封裝提供了一種替代ABF的策略選擇，預計將在2020年代末期實現商業化。

全球先進積體電路基板市場趨勢與洞察

AI/HPC加速器對ABF基板的需求快速成長

2025 代 AI 伺服器的大規模部署導致味之素積層製造膜 (ABF) 供應緊張。 ABF 面板的前置作業時間已超過 35 週，現貨價格較 2024 年合約價格溢價高達 25%。台灣供應商 Unimicron、Kinsus 和南亞 PCB 在經歷了長期的庫存調整後，營收已恢復兩位數成長，但為滿足需求，其運轉率仍維持在 90%。三星馬達在 2025 年第二季提高了其 AI 伺服器的 ABF 產能，並開始試生產玻璃芯。這體現了其為降低單一材料風險而採取的雙源策略。台積電已宣布計劃將 CoWoS 的年產量加倍，這意味著基板需求將顯著超過現有產能。這些發展已使供不應求擴大至 20%，基板製造商預計這種短缺狀況將持續到 2026 年新生產線運作為止。

幾何縮放和異質整合的趨勢

晶片組架構、無芯中介層和穿透矽通孔(TSV) 技術重新定義了封裝設計規則，使生產環境中的基板線寬低於 10µm。應用材料公司強調，與單晶粒方案相比，封裝內整合離散晶片組可實現更高的每瓦性能。凸版印刷推出了一種無芯有機中介層，其熱膨脹係數比傳統的 ABF 解決方案低 45%，從而降低了多晶片堆疊中的機械應力。博通公司的 3.5D XDSiP 技術將超過 6000mm² 的矽晶圓整合到 12 層 HBM 堆疊中，凸顯了對能夠在有限面積內佈線數千個高速訊號的基板的需求。台積電和日月光投資建造了尺寸高達 310x310mm 的面板級封裝生產線，以提高步進馬達效率並降低每平方英吋成本。這些變化正將先進 IC基板市場定位為實現下一代運算密度的關鍵基礎技術。

ABF基板供不應求和前置作業時間突然延長

從2024年到2025年，ABF面板持續的供不應求阻礙了先進IC基板市場的發展。 ABF樹脂的近乎壟斷供應商味之素株式會社承認，在新的樹脂反應器於2026年運作之前，供需缺口將達到20%。台積電表示其只能滿足CoWoS需求的80%，證實了代工廠面臨的限制。積水化學等競爭對手試圖擺脫對積層製造的依賴，但高階AI封裝的認證週期延緩了他們的實施。同時，因其低膨脹係數而備受青睞的T-Glass芯材的短缺，延緩了日東紡的產能擴張，並加劇了前置作業時間的延長。儘管基板製造商實施了在線連續計量以提高一次產量比率並最佳化現有產能，但大多數客戶在2025年之前仍需遵守配額計畫。

細分市場分析

到2025年，FC-BGA基板佔據了先進IC基板市場44.32%的佔有率。其主導地位源自於其久經考驗的電氣性能，而這正是AI加速器和伺服器CPU所必需的。由於GPU製造商競相確保產能，FC - BGA基板的運轉率在2025年全年保持高位。然而，成長重心轉向了用於汽車網域控制器和折疊式行動裝置的剛撓性CSP生產線。軟硬複合CSP的出貨量以7.94%的複合年成長率成長，吸引了能夠平衡彎曲半徑和可控電阻的新型基板供應商。 FC-CSP繼續為中階行動處理器提供基板，但成本壓力限制了平均售價的成長。有機BGA/LGA對於傳統桌面平台仍然很重要，但其設計應用逐漸被覆晶技術所取代。面板級FC基板（歸類為「其他」）已在台積電和日月光開始試生產，實現了單面板七倍的可用面積，並釋放了新的規模經濟效益。

FC-BGA 已成為 CoWoS 堆疊的主要基板。設計人員對 14-26 層電路板的需求日益成長，並對對準公差提出了更高的要求。為此， 基板製造商採用了人工智慧光學檢測設備，以便在堆疊初期階段即可偵測出過孔和走線的錯位。隨著汽車製造商將資訊娛樂系統升級到 15 吋曲面顯示器（需要 Z 軸方向的柔軟性），對軟硬複合CSP 的需求也隨之成長。折疊式設備中攝影機整合度的提高也帶來了額外的需求。預計到 2031 年，這些趨勢將使軟硬複合基板的市場滲透率持續保持成長，而 FC-BGA 將繼續在先進 IC基板市場中保持其高價值地位。

截至2025年，ABF（鋁基複合材料）佔據了先進IC基板市場60.35%的佔有率。味之素株式會社的專有樹脂配方技術確保了穩定的介電性能和可鑽孔性，贏得了客戶在2.5D和3D堆疊方面的信賴。儘管供應商在2025年擴大了ABF混合生產線，但產量成長卻落後於需求，從而鞏固了賣方優勢。玻璃基板在2025年的出貨量佔比不到2%，預計複合年成長率（CAGR）為13.58%。玻璃基板在200 mm x 200 mm的基板上實現了±5 μm的平整度，與ABF相比，能夠實現更精細的線路重布和更高的I/O密度。英特爾退出內部研發驗證了第三方玻璃供應商的可靠性，加速了生態系統的發展。

在汽車控制單元中，BT樹脂仍發揮效用，因為基板溫度通常高達150°C。陶瓷和低溫共燒陶瓷（LTCC）基板為承受持續熱循環的功率元件提供基板，在ABF生產線超賣時，它們能夠提供一定的收入緩衝。玻璃基板的認證在通孔形成均勻性方面遇到了一些挑戰，但最初的原型產品在回流焊接過程中展現了良好的抗翹曲特性。 AMD計畫在2026年CPU平台上使用玻璃化材料，促使基板製造商爭相在量產開始前鎖定生產名額。如果產量比率保持穩定，到2031年，玻璃基板的收入佔有率可能會達到或超過5.3%。

先進 IC基板市場按基板類型（FC-BGA、FC-CSP、有機 BGA/LGA 等）、核心材料（ABF、BT、玻璃等）、封裝技術（2D覆晶、2.5D 中介層等）、裝置節點（28nm 及以上、16/14-10nm 等）、終端用戶（A）、終端用戶、北美區域

區域分析

到2025年，亞太地區將佔據先進積體電路基板市場68.35%的佔有率。台灣的優尼美光、金碩和南亞PCB在人工智慧伺服器需求的推動下，於2025年實現了兩位數的成長，彌補了2023年因庫存調整而導致的出貨量下滑。在日本，台積電位於熊本的工廠憑藉3.9兆日圓（約255億美元）的補貼，重新確立了其在九州的封裝中心地位。韓國宣布了一項4,710億美元的綜合叢集計劃，目標是到2030年實現每月770萬片晶圓的開工量，併計劃在其邏輯晶片工廠附近建設一條ABF-CoWoS生產線。中國推出了區域性激勵措施以擴大覆晶和系統級封裝（SiP）產能，但出口限制制約了製造設備的採購，並減緩了玻璃芯的普及。

在北美，基於《晶片封裝法案》（CHIPS Act）的先進在地化正在推進。台積電位於亞利桑那州的園區正計劃建造六家工廠，並配備ABF生產線以分散風險。 Entegris公司已獲得高達7,500萬美元的聯邦援助，用於基板銅電鍍過濾介質的生產。一家大型OSAT公司正考慮拓展美國市場，以滿足國防工業對晶片封裝的需求，但不斷上漲的薪資水準令人擔憂。

歐洲正聚焦汽車和功率元件領域。安森美半導體位於捷克的碳化矽工廠正在該地區建立一條完整的逆變器基板供應鏈。德國和法國正考慮建立一條聯合ABF（先進基板）試點生產線，以支援英特爾和台積電的晶圓代工業務擴張。與此同時，越南、印度和馬來西亞正在推行組裝補貼計畫。安姆科在北寧省開設了一家價值16億美元的工廠，印度政府核准了760億盧比（約9.1億美元）的OSAT（外包半導體組裝和測試）業務投資，該業務由CG Power和瑞薩電子主導。這些發展進一步分散了先進積體電路基板市場的地理風險。
