3D堆疊式DRAM：市場佔有率分析、產業趨勢與統計數據、成長預測（2026-2031年）

根據 Mordor Intelligence 預測，3D 堆疊式 DRAM 市場規模預計將從 2025 年的 185.4 億美元成長到 2026 年的 244.1 億美元，然後在 2031 年達到 964.8 億美元，2026 年至 2031 年的複合年成長率為 31.6%。

本報告依架構（混合記憶體立方體及類似架構、其他架構）、單棧記憶體容量（4 GB、8 GB、其他）、處理器介面（GPU、AI加速器/ASIC、其他）、應用（AI和資料中心伺服器、高效能運算、其他）以及地區（北美、歐洲、亞太、其他）進行分類。預測值以美元（USD）計價。

全球3D堆疊式DRAM市場趨勢及洞察

人工智慧伺服器和加速器的廣泛應用

3D堆疊式DRAM市場正經歷著翻天覆地的變革，這不僅是因為伺服器出貨量的成長，更是因為大規模模型訓練和推理推動了系統記憶體需求的激增。人工智慧加速器如今需要極高的本地記憶體頻寬，使得堆疊式記憶體成為系統設計的核心元件，而不再只是輔助元件。 2026年1月，NVIDIA宣布其Rubin平台將在每個GPU上整合288GB的HBM4，實現22TB/s的頻寬。與上一代產品相比，這顯著提升了每個加速器封裝的記憶體容量。三星也於2026年2月開始出貨HBM4，標誌著這項轉變正式進入商業供應階段。這表明，產品週期的下一階段不再是理論階段，而是已經進入了全面部署階段。這項轉變也改變了製造商的獎勵，因為與傳統DRAM相比，先進的晶圓生產能力能夠為HBM創造更大的價值，這使得主要供應商更有理由繼續優先發展堆疊式產品。因此，即使整體記憶體市場的部分領域出現下滑，3D堆疊式DRAM市場也可能繼續受到嚴格的產能分配的支撐。

將 HBM 遷移到推理叢集

3D堆疊式DRAM市場也受惠於工作負載配置的變化。這是因為隨著上下文視窗、並髮使用者數量和模型複雜性的增加，推理叢集需要大規模的駐留記憶體池。這不僅增加了記憶體堆疊的出貨量，也提高了每個堆疊的建議容量，使得高密度配置更具商業性吸引力。 JEDEC的HBM4標準透過規定2048位元介面、32個獨立通道以及每個立方體最高支援64GB的容量，推動了這項轉變。這為系統設計人員提供了一條清晰的路徑，無需完全重置控制器即可實現更大的容量。三星在2026年2月更新的藍圖也表明，客製化HBM樣品將於2027年提供給客戶，這暗示了一種採購模式，即超大規模資料中心業者和加速器供應商將更直接地根據推理需求客製化記憶體設計。這一點至關重要。這是因為3D堆疊式DRAM市場不再僅僅依賴通用GPU的生命週期，而是得到了更廣泛的買家群體的支持，他們需要根據自身工作負載特性量身定做的記憶體。因此，尤其是在北美，推理基礎設施的擴展正在擴大高容量HBM的潛在基本客群，而低階需求也變得更加穩定。

TSV 和包裝產量是瓶頸。

3D堆疊式DRAM市場持續面臨根本的製造挑戰。這是因為垂直堆疊的缺陷風險高於傳統的平面DRAM。穿透矽通孔（TSV）細小、深且數量眾多，因此在製造和後續組裝過程中容易出現空隙、接縫缺陷和銅填充不均勻等問題。 SemiEngineering指出，TSV的複雜性仍然是製造瓶頸，這與使用者提供的材料良率持續下降的情況相吻合。隨著供應商轉向12層高密度HBM4堆疊，這個問題更加嚴重，因為晶圓減薄、堆疊對準和鍵合完整性的接受度會隨著層數的增加而降低。即使需求強勁，如果後端製程的損耗仍然很高，可用產量也不會線性成長。因此，3D堆疊式DRAM市場的供應端比僅從終端市場需求推斷出的更為緊張。這也是高價持續存在的原因之一。這是因為低產量生產實際上提高了到達客戶手中的每個認證產品的最低成本。

細分市場分析

到2025年，HBM將佔據3D堆疊DRAM市場73.6%的佔有率，凸顯了AI加速器對高頻寬、低延遲堆疊產品的需求。在3D堆疊DRAM市場，此地位反映的是設計上的現實，而非暫時的價格優勢。因為尖端AI晶片需要能夠靠近邏輯電路放置並傳輸海量數據，同時保持低位元功耗的記憶體。隨著HBM3E和HBM4在主流加速器計畫中的廣泛引進週期，這項架構已然確立，進一步擴大了HBM相對於傳統堆疊方式的領先優勢。 JEDEC HBM4標準透過定義下一代效能標準並維持與HBM3控制器的向下相容性，進一步鞏固了這一趨勢，從而降低了系統設計人員的過渡難度。在3D堆疊DRAM產業，這使得HBM不再只是眾多選擇之一，而是高階加速器記憶體的標竿架構。

雖然其他架構仍然很重要，但它們的應用場景更為有限。 3DS DDR 和 TSV 堆疊式傳統 DRAM 繼續服務於高可靠性和伺服器緩衝記憶體應用，這些應用對頻寬要求不高，認證穩定性比峰值密度更為重要。混合記憶體立方體 (HMC) 及相關設計仍被應用於某些網路和通訊應用，而其他堆疊式變體則支援邊緣 AI 和行動相關工作負載。成長最快的細分市場是“新興混合鍵合和單晶片 3D DRAM”，預計到 2031 年，隨著 3D 堆疊式 DRAM 市場超越傳統熱壓鍵合技術的發展，該細分市場將以 34.4% 的複合年成長率成長。三星計劃於 2026 年推出 HBM4，SK 海力士也公佈了 HBM4 的開發藍圖，這些都顯示封裝和鍵結技術正在發生更廣泛的轉變，不再只是製造細節，而是架構選擇的一部分。因此，3D堆疊DRAM市場的架構構成比在高層較為穩定，但在低層則更加動態，鍵合技術可望塑造下一波差異化浪潮。

在2025年的3D堆疊DRAM市場中，16GB配置佔了33.8%的佔有率。這反映了HBM3E 8層堆疊產品所形成的部署基礎，該產品在上一輪加速器週期中佔據主導地位。從實際應用角度來看，16GB堆疊產品由於其在頻寬、散熱特性和封裝複雜性方面的平衡，大規模。低密度的4GB和8GB規格仍用於傳統的高效能運算（HPC）、網路ASIC和FPGA應用，這些應用的記憶體佔用規模尚未達到最新AI加速器的水平。同時，隨著HBM4商業化的推進，24GB配置正在湧現，三星宣布已出貨首批採用12層堆疊結構的商用HBM4 24GB和36GB版本。此外，JEDEC HBM4 標準透過支援每個立方體高達 64GB 的容量（採用 16 層堆疊），為短期高密度儲存鋪平了道路。這使得計劃在未來幾年內建造加速器平台的客戶能夠更清晰地了解容量擴展藍圖。

預計到2031年，32GB及以上容量的記憶體市場將以32.7%的複合年成長率（CAGR）實現最高成長，這一增速與每一代新加速器對每個封裝的最低記憶體需求不斷提高的趨勢相符。據NVIDIA稱，Rubin R100 GPU整合了288GB的HBM4顯存，實現了22TB/s的頻寬，這表明記憶體設計正明顯轉向更高密度的堆疊配置，而非簡單地增加堆疊數量。這種轉變對3D堆疊DRAM市場具有重大影響，因為中介層面積、組裝插槽以及晶片成本都是阻礙因素，因此，透過減少堆疊數量來提高密度通常比提供多個小型堆疊更具商業性合理性。因此，鑑於機架級系統帶來的記憶體總需求顯著成長，3D堆疊DRAM產業的討論重點正從容量轉向密度。三星推出的 24GB 和 36GB 容量規格以及 JEDEC 規定的 64GB 容量上限表明，容量藍圖已經與這一轉變相符。因此，在 3D 堆疊式 DRAM 市場，預計在整個預測期內，需求中心將沿著容量曲線向上移動。

區域分析

預計到2025年，亞太地區將佔據全球3D堆疊DRAM市場規模的66.7%，並將以32.4%的複合年成長率持續成長至2031年。該地區是3D堆疊DRAM市場的基礎，這主要得益於韓國擁有眾多HBM主要製造商，以及台灣地區在先進共封裝和中介層技術方面的持續領先地位。三星將於2026年2月推出商用HBM4，SK海力士將於2025年9月實現HBM4研發里程碑，這些都表明，市場的大部分技術發展方向仍然由韓國供應商主導。雖然這種區域集中度帶來了規模和執行方面的優勢，但也意味著某些地區的產能限制或封裝延遲可能會對整個3D堆疊DRAM市場產生影響。日本正透過新的 HBM 相關投資活動和旨在提高半導體供應韌性的政策支持，加強其在亞太地區的影響力，從而將該地區擴展到目前以韓國和台灣為中心的框架之外。

北美3D堆疊DRAM市場主要受終端需求而非產量驅動，因為該地區仍是人工智慧加速器系統的最大買家。來自雲端服務和超大規模資料中心業者中心的強勁訂單使北美成為3D堆疊DRAM市場的主要商業性驅動力，儘管大部分供應是在亞太地區製造和封裝的。 NVIDIA Rubin平台的發布就是這種需求驅動的直接例證，因為美國加速器供應商的平台變更會迅速反映在全球供應鏈中新的記憶體需求上。美國產業政策也是一個關鍵因素，因為國內半導體產業的擴張和出口管制框架決定了先進記憶體系統的製造、銷售和部署地點。歐洲仍然是次要的需求中心，但由於政府主導的人工智慧雲端計畫和高效能運算（HPC）的普及，其在3D堆疊DRAM市場的地位正在穩步提升。

儘管世界其他地區在3D堆疊DRAM市場規模仍然較小，但新建資料中心和國家主導的人工智慧專案正在擴大未來的需求範圍。儘管目前存在出口限制，中國仍然是該市場的重要參與者，因為雖然當前一代HBM的取得受到許可法規的限制，但採用老一代技術的國內DRAM生產可以繼續擴大。這形成了雙軌制結構：3D堆疊DRAM市場的尖端技術仍集中在中國以外，而中國供應商則專注於加強其在最尖端科技領域的國內能力。未來，該市場的區域分類將不再主要取決於理論需求的分佈，而是取決於製造、先進封裝、出口合規和終端系統部署等各方面能否協調一致。

其他好處：

• Excel格式的市場預測（ME）表
• 3個月的分析師支持
